2019 Caterpillar 313D

1/6
Used Caterpillar 313D Excavator 2019 Model / 1
Used Caterpillar 313D Excavator 2019 Model / 2
Used Caterpillar 313D Excavator 2019 Model / 3
Used Caterpillar 313D Excavator 2019 Model / 4
Used Caterpillar 313D Excavator 2019 Model / 5
Used Caterpillar 313D Excavator 2019 Model / 6

Product Description

【 Premium Recommendation 】 2019 Caterpillar 313D2GC excavator with a breaker, priced at only 190,000 yuan! This equipment has been in use since 2019. Up to now, it has only been working for about 2,600 hours. With a moderate usage frequency and proper maintenance, its overall condition is excellent. It is equipped with a Caterpillar C4.4 engine. This four-cylinder in-line water-cooled turbocharged diesel engine is renowned for its powerful output and excellent fuel economy, with a maximum power of 75 kilowatts (approximately 100 horsepower), capable of easily handling the operational demands under various complex working conditions. This machine adopts an advanced negative flow control hydraulic system, ensuring smoothness and accuracy during operation. Whether it is excavation, loading or crushing operations, it can handle them with ease. In addition, its unique "intelligent mode" can automatically adjust the output of the pump according to the actual load, further optimizing the energy consumption ratio and reducing operating costs. The standard breaker hammer accessory provides users with more diverse application scenarios to choose from, whether it is urban demolition or mining. The vehicle body structure is sturdy and durable, t

SpecificationsValue
No.970558
Tonnage (tons)13
Working weight (kg)13430
Bucket capacity (m³)0.52
Boom length (mm)4650
Rod length (mm)2500
Country of originXuzhou, Jiangsu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCaterpillar Cat C4.2 ACERT
Rated power (kw/rpm)67 (Net power)
Cooling modewater-cooling
Cylinder diameter × stroke (mm)102 x 130
Number of cylinders (PCS)4
Displacement (L)4.25
Working formMeets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC.
Ground specific pressure (Kpa)41.8 (with 500mm track plate)
Rotation speed (rpm)12.4
Bucket digging force (kN)82
Rod digging force (kN)63
Maximum tractive force (kN)114
Travel speed (km/h)5.5
Main overflow set pressure (Mpa)30.5
Maximum flow of main pump (l/min)127
Traveling Hydraulic Circuit (Mpa)35
Rotary Hydraulic Circuit (Mpa)23
Pilot Oil Circuit (MPa)41.2
Pilot pump flow (L/min)21.9
Bucket cylinders - Number × diameter × stroke (mm)1 x 100 x 939
Bucket rod cylinders - Number × diameter × stroke (mm)1 x 120 x 1197
Boom cylinders - Number × diameter × stroke (mm)2 x 110 x 1015
Fuel Tank (L)250
Hydraulic Tank (L)150
Engine Oil changes (L)19.5
Coolant (L)17.9
Hydraulic System (L)162 (including fuel tank)
Total transport length (mm)7610
Total transport width (mm)2490
Total transport height (mm)2830 (to top of boom)
Full cab height (mm)2760
Counterweight ground clearance (mm)915
Minimum ground clearance (mm)430
Back end turning radius (mm)2140
Total track length (mm)3490
Track gauge (mm)1990
Track plate width (mm)500 (standard)
Total track width (mm)2490
Maximum digging depth (mm)5580
Maximum unloading height (mm)6060
Maximum vertical digging depth (mm)5040
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Maximum excavation radius of stop surface (mm)8220
Boom turning Angle (left/right °)There is no
Maximum effective digging depth (mm)5380
see more

Overview

No.970558

Brand Name:

Caterpillar

Model Number:

313D

Year:

2019

Location:

Zhejiang China
