2016 Caterpillar 320B

1/6
Used Caterpillar 320B Excavator 2016 Model / 1
Used Caterpillar 320B Excavator 2016 Model / 2
Used Caterpillar 320B Excavator 2016 Model / 3
Used Caterpillar 320B Excavator 2016 Model / 4
Used Caterpillar 320B Excavator 2016 Model / 5
Used Caterpillar 320B Excavator 2016 Model / 6

Product Description

"Recommendation of Premium Second-hand Excavators This time, we recommend to you a second-hand excavator with excellent performance and good maintenance. The specific models include Doosan 215, Caterpillar 320B, Kobe Steel 200-7 and many other types. All these devices have undergone strict screening and professional refurbishment to ensure that each machine can meet your engineering requirements. The first one to be introduced is the Doosan 215 excavator, which is equipped with an original imported middle arm cylinder and has a working time of approximately 4,000 hours, being in the best working condition. This model adopts an efficient and energy-saving power system and is equipped with a high-performance engine. It not only has strong power but also good fuel economy, which can effectively reduce operating costs. In terms of the hydraulic system, advanced load sensing technology has been adopted, which makes the operation more precise and smooth, and greatly improves work efficiency. Next up is the Caterpillar 320B. This machine also features high-quality middle arm cylinders and small arm cylinders, with a cumulative working time of approximately 5,500 hours. It is equipped with Caterpillar's independently developed C series engi

SpecificationsValue
No.965604
Tonnage (tons)20
Working weight (kg)19400
Bucket capacity (m³)0.92
Boom length (mm)5680
Rod length (mm)2900
Country of originJapan
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCaterpillar CAT 3066T
Rated power (kw/rpm)99.9/1800
Cylinder diameter × stroke (mm)102 x 130
Displacement (L)6.4
Rotation speed (rpm)10.7
Travel speed (km/h)3.4/5.5
Maximum flow of main pump (l/min)185
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)23
Working Hydraulic Circuit (Mpa)34.3
Pilot Oil Circuit (MPa)4.12
Bucket cylinders - Number × diameter × stroke (mm)1-120 x 1030
Bucket rod cylinders - Number × diameter × stroke (mm)1-140 x 1430
Boom cylinders - Number × diameter × stroke (mm)2-120 x 1260
Fuel Tank (L)340
Hydraulic Tank (L)130
Engine Oil changes (L)20.5
Coolant (L)25
Hydraulic System (L)220
Total transport length (mm)9440
Total transport width (mm)2800
Total transport height (mm)2940
Full cab height (mm)2940
Minimum ground clearance (mm)475
Back end turning radius (mm)2750
Track gauge (mm)2200
Track plate width (mm)600
Total track width (mm)2800
Track ground length (mm)3265
Maximum digging depth (mm)6640
Maximum excavation height (mm)9470
Maximum unloading height (mm)6570
Maximum vertical digging depth (mm)6040
Maximum excavation radius of stop surface (mm)9780
see more

Overview

No.965604

Brand Name:

Caterpillar

Model Number:

320B

Year:

2016

Location:

Fujian China
