2016 Caterpillar 320C
Product Description
Engineered with Caterpillar's proven CAT 3066 ATAAC engine delivering 110kW at 1800 RPM, this 2016 320C excavator combines robust hydraulic performance with exceptional reliability. The advanced hydraulic system operates at 34.3 MPa working pressure with a 205 L/min main pump flow rate, ensuring precise control and maximum productivity across demanding applications.
Built on Caterpillar's renowned 320 series platform, this 20-ton machine features superior digging capabilities with 132kN bucket force and 99kN rod force. Key specifications include:
- 6.4L displacement engine with water-cooling system
- 9.71m maximum excavation radius and 6.55m digging depth
- 0.8m³ bucket capacity with 5.68m boom reach
- 320L fuel tank for extended operation cycles
- Dual boom cylinders (2-120 x 1260mm) for enhanced lifting power
Located in Guangdong, China, this joint venture manufactured unit represents proven Caterpillar engineering quality. With 48.02 kPa ground pressure and 11.5 RPM rotation speed, it delivers optimal performance while minimizing ground disturbance across construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 951435 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Overview
No.951435
Brand Name：
CaterpillarModel Number：
320CYear：
2016
Location：
Guangdong China
