Product Description

This second-hand Caterpillar 329 excavator is an ideal choice for pure earthwork operations, especially suitable for engineering projects that require high efficiency and stable performance. Since its manufacture, this machine has always maintained a good maintenance condition, with a cumulative working time of only 6,000 hours. For a medium-sized excavator, this service life indicates that it still has a long service life and excellent cost performance. In terms of the power system, the Carter 329 is equipped with the Cat C7.1 ACERT engine. This engine is renowned for its powerful output and smooth operation. While providing sufficient horsepower, it also ensures a low fuel consumption rate, making it highly suitable for use in long-term and high-intensity working environments. In addition, the advanced exhaust gas recirculation technology (EGR) combined with diesel particulate filters (DPF) not only meets strict emission standards but also effectively extends the service life of the engine. The hydraulic system is another highlight of this excavator. It adopts Caterpillar's unique positive flow control technology, which can automatically adjust the pumping volume according to the actual operation requirements, ensuring that each ac

SpecificationsValue
No.963958
Tonnage (tons)29
Working weight (kg)29240
Bucket capacity (m³)1.1
Boom length (mm)6150
Rod length (mm)3200
Country of originJapan
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeC7ACERT
Rated power (kw/rpm)152/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)110 x 127
Number of cylinders (PCS)6
Displacement (L)7.2
Rotation speed (rpm)10.2
Climbing ability (%)70/35 °
Travel speed (km/h)3.5/5.3
Main overflow set pressure (Mpa)3.5
Maximum flow of main pump (l/min)235
Traveling Hydraulic Circuit (Mpa)3.5
Rotary Hydraulic Circuit (Mpa)2.75
Hydraulic crushing pipeline is standardno
Working Hydraulic Circuit (Mpa)3.5
Pilot Oil Circuit (MPa)3.9
Bucket cylinders - Number × diameter × stroke (mm)135 x 1156
Bucket rod cylinders - Number × diameter × stroke (mm)150 x 1646
Boom cylinders - Number × diameter × stroke (mm)140 x 1407
Fuel Tank (L)520
Hydraulic Tank (L)145
Engine Oil changes (L)30
Coolant (L)30
Hydraulic System (L)310(including fuel tank)
Total transport length (mm)10410
Total transport width (mm)3190
Total transport height (mm)3180
Full cab height (mm)3040
Counterweight ground clearance (mm)1110
Minimum ground clearance (mm)490
Back end turning radius (mm)3080
Total track length (mm)4860
Track gauge (mm)2590
Track plate width (mm)800
Total track width (mm)3190
Track ground length (mm)3990
Maximum digging depth (mm)7170
Maximum excavation height (mm)9990
Maximum unloading height (mm)7020
Maximum vertical digging depth (mm)6510
Bulldozer lift or depth (mm)No bulldozer
Dodging plate width × height (mm)No bulldozer
Maximum excavation radius of stop surface (mm)10600
Maximum effective digging depth (mm)7010
see more

Overview

No.963958

Brand Name:

Caterpillar

Model Number:

329DL

Year:

2019

Location:

Hebei China
