2018 Caterpillar 340D2L

1/9
Used Caterpillar 340D2L Excavator 2018 Model / 1
Used Caterpillar 340D2L Excavator 2018 Model / 2
Used Caterpillar 340D2L Excavator 2018 Model / 3
Used Caterpillar 340D2L Excavator 2018 Model / 4
Used Caterpillar 340D2L Excavator 2018 Model / 5
Used Caterpillar 340D2L Excavator 2018 Model / 6
Used Caterpillar 340D2L Excavator 2018 Model / 7
Used Caterpillar 340D2L Excavator 2018 Model / 8
Used Caterpillar 340D2L Excavator 2018 Model / 9

Product Description

【 Premium Recommendation 】 A top-quality 18-year-old Caterpillar 340D2L pure earthmoving machine. We sincerely invite you to purchase it! This excavator is a Caterpillar 340D2L model produced in 2018, specially designed for earthwork operations. Up to now, its working hours are only over 3,000 hours. For a large excavator, this usage time is very short and can almost be regarded as nearly new. Its overall performance is extremely superior. In terms of power, this machine is equipped with a Caterpillar C9.3 ACERT engine, with a maximum output power of up to 225 kilowatts (approximately 302 horsepower). It not only has strong power but also excellent fuel economy, capable of meeting the operational requirements under various complex working conditions. In addition, this engine also adopts advanced emission control technology, meeting the latest environmental protection standards. This enables you to enjoy efficient work while actively responding to the national call for green construction. In terms of the hydraulic system, the 340D2L is equipped with a closed center load sensing hydraulic system independently developed by Caterpillar, ensuring the response speed and accuracy of the machine during operation. Whether it is tasks such as

SpecificationsValue
No.969022
Tonnage (tons)40
Working weight (kg)38900~41500
Bucket capacity (m³)1.9
Boom length (mm)6500
Rod length (mm)2800
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCatC9
Rated power (kw/rpm)208
Cylinder diameter × stroke (mm)112 x 149
Displacement (L)8.8
Working formDirect injection fuel system with turbocharger aftercooler
Rotation speed (rpm)8.3
Climbing ability (%)70
Bucket digging force (kN)210
Rod digging force (kN)185
Maximum tractive force (kN)300
Travel speed (km/h)4.6
Turning torque (Nm)109
Main overflow set pressure (Mpa)35
Maximum flow of main pump (l/min)281
Traveling Hydraulic Circuit (Mpa)35
Rotary Hydraulic Circuit (Mpa)28
Pilot Oil Circuit (MPa)4
Pilot pump flow (L/min)40
Bucket cylinders - Number × diameter × stroke (mm)150 x 1151
Bucket rod cylinders - Number × diameter × stroke (mm)170 x 1738
Boom cylinders - Number × diameter × stroke (mm)150 x 1440
Fuel Tank (L)175
Hydraulic Tank (L)620
Engine Oil changes (L)41
Coolant (L)40
Hydraulic System (L)410
Total transport length (mm)11170
Total transport width (mm)3620
Total transport height (mm)3630
Full cab height (mm)3360
Counterweight ground clearance (mm)1450
Minimum ground clearance (mm)742
Back end turning radius (mm)3490
Total track length (mm)5060
Track gauge (mm)2920
Track plate width (mm)600
Maximum digging depth (mm)7190
Maximum excavation height (mm)10330
Maximum unloading height (mm)7000
Maximum vertical digging depth (mm)5460
Maximum excavation radius of stop surface (mm)10830
Maximum effective digging depth (mm)6370
see more

Overview

No.969022

Brand Name:

Caterpillar

Model Number:

340D2L

Year:

2018

Location:

Guangdong China
