2018 Doosan DX230LC-9C
Product Description
The Doosan 230-9C from 2018 has good performance and appearance. It's a first-hand car from the customer. The actual price is over 10,000 yuan. There are a large number of detailed pictures and videos. The price is 218,000 yuan.
| Specifications | Value |
|---|---|
| No. | 957541 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22020 |
| Bucket capacity (m³) | 1.2 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DL06 |
| Rated power (kw/rpm) | 115/1900 |
| Cylinder diameter × stroke (mm) | 100*125 |
| Number of cylinders (PCS) | 6 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 10.5 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 105 |
| Travel speed (km/h) | 5.7/3.1 |
| Maximum flow of main pump (l/min) | 2*212 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120*80*1060 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-135*95*1443 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-125*85*1263 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 27 |
| Total transport length (mm) | 9506 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 2950 |
| Full cab height (mm) | 2985 |
| Counterweight ground clearance (mm) | 1096 |
| Minimum ground clearance (mm) | 475 |
| Back end turning radius (mm) | 2794 |
| Total track length (mm) | 4440 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 9873 |
| Maximum digging depth (mm) | 6592 |
| Maximum excavation height (mm) | 9616 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 3929 |
| Maximum excavation radius of stop surface (mm) | 9699 |
see more
Overview
No.957541
Brand Name：
DoosanModel Number：
DX230LC-9CYear：
2018
Location：
Shandong China
