2018 Doosan DX260LC-9C
Product Description
Selling and transferring good excavators Top-quality Doosan DX260, perfectly crafted as a quality representative. It's the boss 's first-hand vehicle, all original versions. After the construction site is completed, you can go home and start working directly. Bosses who want to buy, hurry up and act. Don't miss the opportunity. For nationwide shipping and ordering, please call ☎️☎️
| Specifications | Value |
|---|---|
| No. | 942977 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25060 |
| Bucket capacity (m³) | 1.4 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DL06A-C3 |
| Rated power (kw/rpm) | 140 / 2200 |
| Cylinder diameter × stroke (mm) | 100 *125 |
| Number of cylinders (PCS) | 6 |
| Working form | orthostitial |
| Rotation speed (rpm) | 10.0 |
| Bucket digging force (kN) | 166.6 |
| Rod digging force (kN) | 114.7 |
| Travel speed (km/h) | 5.8 / 3.4 |
| Turning torque (Nm) | 8140 |
| Maximum flow of main pump (l/min) | 2 x 219 |
| Fuel Tank (L) | 410 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 10,055 |
| Total transport width (mm) | 3,200 |
| Total transport height (mm) | 2,960 |
| Full cab height (mm) | 845 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2,995 |
| Onboard width (mm) | 1,010 |
| Total track length (mm) | 4,625 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3,200 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 10 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10175 |
| Maximum digging depth (mm) | 6810 |
| Maximum excavation height (mm) | 9,705 |
| Maximum unloading height (mm) | 7024 |
| Maximum vertical digging depth (mm) | 4742 |
| Maximum excavation radius of stop surface (mm) | 10,004 |
| Maximum effective digging depth (mm) | 6810 |
see more
Overview
No.942977
Brand Name：
DoosanModel Number：
DX260LC-9CYear：
2018
Location：
Hebei China
