2020 Doosan DX520LC-9C
Product Description
The price of Doosan's 2020 DX520LC-9C is over 400,000 yuan
| Specifications | Value |
|---|---|
| No. | 945365 |
| Tonnage (tons) | 52 |
| Working weight (kg) | 50800 |
| Bucket capacity (m³) | 2.72~3.2 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DC13 |
| Rated power (kw/rpm) | 257/1800 |
| Cylinder diameter × stroke (mm) | 130*160 |
| Number of cylinders (PCS) | 6 |
| Rotation speed (rpm) | 8.3 |
| Bucket digging force (kN) | 266.6/282.2 |
| Rod digging force (kN) | 233.2/247.0 |
| Travel speed (km/h) | 5.3/3.1 |
| Turning torque (Nm) | 16304 |
| Maximum flow of main pump (l/min) | 2*355 |
| Traveling Hydraulic Circuit (Mpa) | 33 |
| Rotary Hydraulic Circuit (Mpa) | 30 |
| Control Hydraulic Circuit (Mpa) | 35 |
| Main pump type | Variable axial piston pump |
| Working Hydraulic Circuit (Mpa) | 33 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-170*115*1341 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-190*130*1980 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-170*115*1650 |
| Fuel Tank (L) | 626 |
| Hydraulic Tank (L) | 390 |
| Engine Oil changes (L) | 45 |
| Coolant (L) | 51 |
| Total transport length (mm) | 11530 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 4125 |
| Counterweight ground clearance (mm) | 1460 |
| Minimum ground clearance (mm) | 770 |
| Minimum turning radius of front working device (mm) | 5120 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5455 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 3 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 53 |
| Maximum digging radius (mm) | 10765 |
| Maximum digging depth (mm) | 6765 |
| Maximum excavation height (mm) | 9705 |
| Maximum unloading height (mm) | 6750 |
| Maximum excavation radius of stop surface (mm) | 10475 |
| Maximum effective digging depth (mm) | 10475 |
see more
Overview
No.945365
Brand Name：
DoosanModel Number：
DX520LC-9CYear：
2020
Location：
Guangdong China
