Product Description
【 Doosan 380 Second-hand Excavator This second-hand Doosan 380 excavator is your reliable assistant in all kinds of engineering operations. This equipment has a working time of only 2,500 hours. With proper maintenance, its performance is stable and reliable. It is equipped with a high-performance six-cylinder turbocharged engine, which features powerful output and smooth operation characteristics. Even in complex and changeable working environments, it can handle them with ease. Whether it is digging, loading or leveling the land, it can demonstrate outstanding work efficiency. In terms of the hydraulic system, Doosan 380 is equipped with an advanced closed center load sensing hydraulic control system, which ensures accuracy and response speed during operation, while reducing energy consumption and improving fuel economy. Its unique hydraulic oil cooling technology can effectively prevent overheating and extend the service life of the entire system. In addition, this model also pays special attention to the driver's comfort experience. The spacious cab design combined with a good field of vision makes long working hours no longer a burden. To sum up, this second-hand Doosan 380 excavator not only boasts outstanding performance but
| Specifications | Value |
|---|---|
| No. | 960283 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
