Product Description
This Doosan 380-9C excavator from 2018 is a medium to large-sized excavator that has received high praise in the market. It has a working time of over 2,000 hours, but the overall condition of the vehicle is excellent and can almost be called a masterpiece. This not only demonstrates its durability and reliability, but also reflects the previous owner's good maintenance and care for it. The Doosan 380-9C is equipped with an efficient diesel engine, which can provide strong power output and ensure stable and efficient operation under various complex working conditions. Its advanced power management system can automatically adjust the engine speed according to the actual operation requirements, thereby achieving a balance between the best fuel economy and performance. In terms of the hydraulic system, this model adopts the latest electronically controlled hydraulic technology, featuring fast response speed, high control accuracy and smooth operation feel. Whether it is excavation or loading operations, they can all be handled with ease, greatly improving work efficiency. In addition, its powerful digging force and flexible boom design enable it to complete tasks with ease even in narrow Spaces. In conclusion, this Doosan 380-9C excava
| Specifications | Value |
|---|---|
| No. | 969396 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
