HOME>>Brands>>Kobelco SK200-8

2016 Kobelco SK200-8

1/9
Used Kobelco SK200-8 Excavator 2016 Model / 1
Used Kobelco SK200-8 Excavator 2016 Model / 2
Used Kobelco SK200-8 Excavator 2016 Model / 3
Used Kobelco SK200-8 Excavator 2016 Model / 4
Used Kobelco SK200-8 Excavator 2016 Model / 5
Used Kobelco SK200-8 Excavator 2016 Model / 6
Used Kobelco SK200-8 Excavator 2016 Model / 7
Used Kobelco SK200-8 Excavator 2016 Model / 8
Used Kobelco SK200-8 Excavator 2016 Model / 9

Product Description

【 Premium Recommendation 】 Second-hand Kobelco SK200-8 excavator, currently priced at over 70,000 yuan, offers an extremely high cost performance and is your ideal choice for engineering operations. Since this excavator was put into use in 2010, its cumulative working time has only been about 4,500 hours, which is far lower than the average service life of similar equipment. The mechanical condition is good and its performance is stable and reliable. In terms of the power system, this machine is equipped with an original imported Isuzu engine, which is powerful and has excellent fuel economy, and can easily handle the high-load operation requirements under various complex working conditions. It can maintain efficient operation even in harsh environments, providing continuous power support for your engineering projects. In addition, this engine also features excellent durability and ease of maintenance, significantly reducing the cost of later maintenance. The hydraulic system adopts advanced negative flow control technology, ensuring rapid action response and smooth operation. Whether it is excavation, loading or crushing operations, it can handle them with ease. Meanwhile, thanks to the optimized design of the main pump and motor co

SpecificationsValue
No.962627
Tonnage (tons)20
Working weight (kg)20600
Bucket capacity (m³)0.8
Rod length (mm)2.94
Country of originHangzhou
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeHino J05E
Rated power (kw/rpm)114/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)112 x 130
Number of cylinders (PCS)4
Displacement (L)5.123
Working formDirect injection, four stroke, turbocharged, built-in intercooling
Ground specific pressure (Kpa)46
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)143
Rod digging force (kN)102
Travel speed (km/h)3.6/6.0
Maximum flow of main pump (l/min)2 x 220
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)29
Control Hydraulic Circuit (Mpa)5
Hydraulic crushing pipeline is standardis
Main pump typeDual variable displacement axial piston pump ×2+ pilot gear pump ×1
Working Hydraulic Circuit (Mpa)34.3
Bucket cylinders - Number × diameter × stroke (mm)120 x 1080
Bucket rod cylinders - Number × diameter × stroke (mm)135 x 1558
Boom cylinders - Number × diameter × stroke (mm)120 x 1355
Fuel Tank (L)370
Hydraulic Tank (L)146
Engine Oil changes (L)22
Coolant (L)22
Total transport length (mm)9450
Total transport width (mm)2800
Total transport height (mm)2980
Counterweight ground clearance (mm)1060
Minimum ground clearance (mm)450
Minimum turning radius of front working device (mm)3540
Back end turning radius (mm)2750
Total track length (mm)4170
Track gauge (mm)2200
Track plate width (mm)600/700/800
Total track width (mm)2800
Track ground length (mm)3370
Maximum digging radius (mm)9900
Maximum digging depth (mm)6700
Maximum excavation height (mm)9720
Maximum unloading height (mm)6910
Maximum vertical digging depth (mm)6100
Bulldozer lift or depth (mm)No bulldozer
Dodging plate width × height (mm)No bulldozer
Maximum excavation radius of stop surface (mm)9730
Maximum effective digging depth (mm)6520
see more

Overview

No.962627

Brand Name:

Kobelco

Model Number:

SK200-8

Year:

2016

Location:

Zhejiang China
