2016 Kobelco SK200-8

1/9
Used Kobelco SK200-8 Excavator 2016 Model / 1
Used Kobelco SK200-8 Excavator 2016 Model / 2
Used Kobelco SK200-8 Excavator 2016 Model / 3
Used Kobelco SK200-8 Excavator 2016 Model / 4
Used Kobelco SK200-8 Excavator 2016 Model / 5
Used Kobelco SK200-8 Excavator 2016 Model / 6
Used Kobelco SK200-8 Excavator 2016 Model / 7
Used Kobelco SK200-8 Excavator 2016 Model / 8
Used Kobelco SK200-8 Excavator 2016 Model / 9

Product Description

【 Premium Recommendation 】 Second-hand Kobelco SK200-8 excavator, priced at 98,000 yuan, supports on-site trial operation, allowing you to experience its outstanding performance firsthand! [666] [666] This Kobelco SK200-8 excavator has a working duration of only 4,500 hours. With proper maintenance, it is in excellent overall condition. It is equipped with the highly efficient and energy-saving Isuzu AH-4HK1X engine, which is renowned for its powerful power output and excellent fuel economy, and can maintain stable and reliable performance under various working conditions. Whether it's excavation, loading or crushing operations, they can all be handled with ease, meeting your diverse needs. In terms of the hydraulic system, advanced negative flow control technology is adopted, ensuring smoother and more fluid operation, rapid response, while reducing energy consumption and improving work efficiency. In addition, this model is also equipped with an automatic idle function, which further saves fuel consumption and reduces operating costs. In terms of appearance, there is no obvious damage to the vehicle body, and the paint surface is as smooth as new. The interior of the cab is clean and comfortable, the layout of the operation interf

SpecificationsValue
No.965211
Tonnage (tons)20
Working weight (kg)20600
Bucket capacity (m³)0.8
Rod length (mm)2.94
Country of originHangzhou
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeHino J05E
Rated power (kw/rpm)114/2000
Cooling modewater-cooling
Cylinder diameter × stroke (mm)112 x 130
Number of cylinders (PCS)4
Displacement (L)5.123
Working formDirect injection, four stroke, turbocharged, built-in intercooling
Ground specific pressure (Kpa)46
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)143
Rod digging force (kN)102
Travel speed (km/h)3.6/6.0
Maximum flow of main pump (l/min)2 x 220
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)29
Control Hydraulic Circuit (Mpa)5
Hydraulic crushing pipeline is standardis
Main pump typeDual variable displacement axial piston pump ×2+ pilot gear pump ×1
Working Hydraulic Circuit (Mpa)34.3
Bucket cylinders - Number × diameter × stroke (mm)120 x 1080
Bucket rod cylinders - Number × diameter × stroke (mm)135 x 1558
Boom cylinders - Number × diameter × stroke (mm)120 x 1355
Fuel Tank (L)370
Hydraulic Tank (L)146
Engine Oil changes (L)22
Coolant (L)22
Total transport length (mm)9450
Total transport width (mm)2800
Total transport height (mm)2980
Counterweight ground clearance (mm)1060
Minimum ground clearance (mm)450
Minimum turning radius of front working device (mm)3540
Back end turning radius (mm)2750
Total track length (mm)4170
Track gauge (mm)2200
Track plate width (mm)600/700/800
Total track width (mm)2800
Track ground length (mm)3370
Maximum digging radius (mm)9900
Maximum digging depth (mm)6700
Maximum excavation height (mm)9720
Maximum unloading height (mm)6910
Maximum vertical digging depth (mm)6100
Bulldozer lift or depth (mm)No bulldozer
Dodging plate width × height (mm)No bulldozer
Maximum excavation radius of stop surface (mm)9730
Maximum effective digging depth (mm)6520
see more

Overview

No.965211

Brand Name:

Kobelco

Model Number:

SK200-8

Year:

2016

Location:

Guangdong China
