Product Description
【 Premium Recommendation 】 Kobelco SK330-10 excavator from 2017, with a working time of over 8,000 hours, is now on sale at an extremely favorable price! Since its commissioning in 2017, this Kobelco SK330-10 excavator has performed outstandingly in numerous large-scale engineering projects, thanks to its outstanding performance and reliable quality. The equipment has accumulated a working time of over 8,000 hours and is in good operating condition. It has complete maintenance records and regular maintenance and upkeep are carried out to ensure its efficient operation. In terms of power, this machine is equipped with a high-performance Isuzu engine, with a maximum power output of 194kW (approximately 262 horsepower). It not only has strong power but also excellent fuel economy, capable of meeting the operational requirements under various complex working conditions. In addition, the advanced electronic control system further enhances fuel efficiency and reduces operating costs. The hydraulic system is a major highlight of this excavator. It adopts the latest CLSS closed center load sensing system, which features fast response speed and smooth operation. This makes the entire machine more flexible and effortless during excavation, lo
| Specifications | Value |
|---|---|
| No. | 968696 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 34500 |
| Bucket capacity (m³) | 1.5 |
| Rod length (mm) | 3300 |
| Bucket width (mm) | 1390 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Hino J08ETM-KSDL |
| Rated power (kw/rpm) | 209/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 998/1600 |
| Working form | Direct injection, water-cooled, four-stroke, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 70 |
| Rotation speed (rpm) | 10.0 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 165 |
| Maximum tractive force (kN) | 333 |
| Travel speed (km/h) | 5.6/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Axial piston pump motor ×1 |
| Type of walking hydraulic motor | Variable capacity axial piston motor x 2 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Fuel Tank (L) | 503 |
| Hydraulic Tank (L) | 245 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11300 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3430 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1190 |
| Minimum ground clearance (mm) | 500 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3720 |
| Maximum digging radius (mm) | 11260 |
| Maximum digging depth (mm) | 7560 |
| Maximum excavation height (mm) | 10540 |
| Maximum unloading height (mm) | 7370 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11060 |
