Product Description
【 Premium Recommendation 】2024 Sany 245H second-hand excavator, meeting National IV emission standards, with warranty service, the overall condition of the vehicle is close to that of a new one! This 2024 Sany 245H excavator has only been in operation for 1,200 hours and is in excellent condition, almost as good as a new car. The entire machine adopts a high-performance power system and is equipped with an efficient engine independently developed by Sany. It is powerful and has excellent fuel economy, meeting the latest National IV emission standards. It is not only environmentally friendly but also can significantly reduce operating costs. In terms of the hydraulic system, it is equipped with an advanced negative flow control system, ensuring more precise and smooth operation, while reducing energy consumption and improving work efficiency. In addition, this excavator is specially equipped with Sany's original hammer tubing, providing you with more flexibility and multi-functionality for your construction. Whether it's excavation, crushing or other complex working conditions, it can handle them with ease. The entire vehicle has undergone strict quality inspection and enjoys the warranty service provided by Sany, allowing you to purc
| Specifications | Value |
|---|---|
| No. | 969261 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
