Product Description
【 Recommendation for Premium Second-hand Excavators 】 The XCMG XE135D, which was first used in early 2021, has only one user and is used on-site throughout the process, ensuring its excellent working condition and maintenance record. So far, the cumulative working time of this excavator is only about 1,800 hours, which is far lower than the average service life of similar equipment. This means that it still has a long service life to wait for excavation. In terms of the power system, the XCMG XE135D is equipped with an efficient and energy-saving engine, which can provide strong and stable power output. It can handle both hard rocks and soft soil with ease. More importantly, this engine adopts advanced fuel injection technology, which not only improves fuel efficiency but also significantly reduces emission pollution. It meets current environmental protection requirements while also saving operating costs for enterprises. The hydraulic system is one of the key factors in evaluating the performance of an excavator. This machine adopts a closed-loop system composed of fully imported high-quality hydraulic components, featuring fast response speed, high control accuracy and good operation feel. Especially when working in complex terrain
| Specifications | Value |
|---|---|
| No. | 966665 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13200 |
| Bucket capacity (m³) | 0.32-0.61 (0.52) |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSF3.8 |
| Rated power (kw/rpm) | 86/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 470/1300 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.8 |
| Working form | Efi, Direct injection, 4-stroke, turbocharged |
| Ground specific pressure (Kpa) | 40.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 99.1 |
| Rod digging force (kN) | 68 |
| Maximum tractive force (kN) | 134 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 125.4*2 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Working Hydraulic Circuit (Mpa) | 31.4/34.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 105 |
| Engine Oil changes (L) | 11 |
| Total transport length (mm) | 7795 |
| Total transport width (mm) | 2525 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 931 |
| Minimum ground clearance (mm) | 466 |
| Minimum turning radius of front working device (mm) | 2445 |
| Back end turning radius (mm) | 2325 |
| Total track length (mm) | 3648 |
| Track gauge (mm) | 1990 |
| Total track width (mm) | 500 |
| Maximum digging radius (mm) | 8304 |
| Maximum digging depth (mm) | 5546 |
| Maximum excavation height (mm) | 8638 |
| Maximum unloading height (mm) | 6174 |
| Maximum vertical digging depth (mm) | 4698 |
| Maximum effective digging depth (mm) | 5335 |
