Product Description
【 Premium Recommendation 】2021 XCMG XE135 second-hand excavator, with outstanding performance and reliable quality, priced at only 159,000 yuan! Since its manufacture, this excavator has only worked for a total of 1,800 hours. With low usage frequency and proper maintenance, the overall condition of the vehicle is excellent. It is a rare high cost-performance choice in the market. In terms of the power system, this device is equipped with an original imported Cummins engine, which features strong power output and smooth operation characteristics. Even in harsh working environments, it can ensure efficient and stable operation performance. Meanwhile, advanced fuel injection technology leads to lower fuel consumption and better economy, significantly reducing users' operating costs. The hydraulic system adopts core components of internationally renowned brands, ensuring the sensitivity and accuracy of the entire machine's operation. Whether it is in complex working conditions such as excavation, loading or crushing, it can handle them with ease and demonstrate outstanding work efficiency. In addition, the intelligent control system can monitor and adjust various parameters in real time, effectively extending the service life of the equ
| Specifications | Value |
|---|---|
| No. | 964262 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1640 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 23.8 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi |
| Pilot pump flow (L/min) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1080 |
| Total transport height (mm) | 2400 |
| Counterweight ground clearance (mm) | 472 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 850 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2320 |
| Maximum excavation height (mm) | 3615 |
| Maximum unloading height (mm) | 2480 |
| Maximum vertical digging depth (mm) | 1520 |
| Dodging plate width × height (mm) | 1080*225 |
