Product Description
【 Second-hand XCMG XE135 Excavator Model: XCMG XE135 Price: 69,800 yuan This second-hand XCMG XE135 excavator boasts outstanding performance and an extremely high cost-performance ratio. Its working time is only 2,400 hours. The overall mechanical condition is good, with no major accident records and proper maintenance. It is very suitable for the usage requirements of medium and small-sized engineering projects. In terms of the power system, this machine is equipped with an original imported engine, which is powerful, stable and reliable, and can easily meet the operation requirements under various complex working conditions. Even under long-term high-load working conditions, it can still maintain a good operating state, greatly improving work efficiency. Meanwhile, advanced fuel injection technology leads to lower fuel consumption, saving users a significant amount of cost. The hydraulic system is a major highlight of this excavator. It adopts a combination of high-efficiency and energy-saving hydraulic pumps and motors provided by internationally renowned brands, ensuring smooth operation and rapid response of the entire machine. Both the digging force and the rotation speed have reached the industry-leading level, making it par
| Specifications | Value |
|---|---|
| No. | 965268 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
