| Specifications | Value |
|---|---|
| No. | 962971 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20120 |
| Bucket capacity (m³) | 1.1/0.48/1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Case case 659TA-M2 |
| Rated power (kw/rpm) | 129/2000 |
| Total displacement (L) | 5.9 |
| Forward speed (Km/h) | 25 |
| Rotation speed (rpm) | 9.5 |
| Main overflow set pressure (Mpa) | 24 |
| Fuel Tank (L) | 325 |
| Engine Oil changes (L) | 16 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 160 |
| Total transport length (mm) | 9675 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 3219 |
| Full cab height (mm) | 3170 |
| Counterweight ground clearance (mm) | 1320 |
| Wheelbase (mm) | 2750 |
| Total tire outside width (mm) | 2540 |
| Minimum ground clearance (mm) | 390 |
| Back end turning radius (mm) | 2750 |
| Maximum excavation radius (mm) | 9600 |
| Maximum digging depth (mm) | 6000 |
| Maximum excavation height (mm) | 9900 |
| Maximum unloading height (mm) | 7200 |
| Maximum vertical digging depth (mm) | 4200 |
Description
Detailed Introduction to the Used Case 240 Excavator This second-hand Case 240 excavator has a working time of up to 8,000 hours, yet its performance remains outstanding, which is sufficient proof of the durability and reliability of this equipment. This aircraft is equipped with an efficient in-line four-cylinder water-cooled turbocharged engine, with a maximum output power of up to 160 horsepower (approximately 120 kilowatts), providing strong and stable power support under various complex working conditions. In addition, it is equipped with an advanced electronic fuel injection system, which not only improves fuel efficiency and reduces emissions, but also lowers operating costs. In terms of the hydraulic system, the Case 240 adopts a closed center load sensing hydraulic control system, which can achieve precise operation response and smooth action transition. Whether it is excavation, loading or crushing operations, it can handle them with ease. It is worth mentioning that this excavator has particularly enhanced the design strength of structural components, such as the reinforced boom and bucket arm and other key parts, enabling it to maintain a long-term stable working state even in high-intensity working environments. It can
