2016 Caterpillar 312C











| Specifications | Value |
|---|---|
| No. | 965991 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12777.7 |
| Bucket capacity (m³) | 0.55 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 3000 |
| Country of origin | Japan/Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | 3046T |
| Rated power (kw/rpm) | 70.1/1950 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 4.3 |
| Rotation speed (rpm) | 12.9 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 62 |
| Rod digging force (kN) | 96 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 126.8 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.3 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.05 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 17.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162(including fuel tank) |
| Total transport length (mm) | 7570 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2760 |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2780 |
| Maximum digging depth (mm) | 5550 |
| Maximum excavation height (mm) | 8475 |
| Maximum unloading height (mm) | 6095 |
| Maximum vertical digging depth (mm) | 4970 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8175 |
Description
【 Premium Recommendation 】 The top-quality original paint Caterpillar 312C excavator. This machine has maintained an excellent working condition since its manufacture, with a working time of only 1,500 hours, which is equivalent to one-third of the usage time of most second-hand excavators of the same model on the market. In terms of appearance, this machine adopts a 90% low seat design. Not only does it look neat and new, but it also makes it more convenient for the operator to get on and off the vehicle. At the same time, it lowers the center of gravity of the entire machine, improving the stability of operation. In terms of power, the Caterpillar 312C is equipped with the highly efficient and reliable CAT C4.4 engine, with a maximum power output of up to 67kW. While ensuring strong power output, its fuel consumption performance is also excellent, capable of meeting the demands under various working conditions. The hydraulic system adopts advanced load sensing technology, ensuring smooth operation and response speed. Whether it is excavation, loading or crushing operations, it can handle them with ease, truly achieving an efficient operation experience like "airplane speed". In addition, this equipment retains the original circuit
Overview
No.965991
Brand Name:
CaterpillarModel Number:
312CYear:
2016
Location:
Guangdong China
