2014 Caterpillar 312D








Product Description
This 2014 Caterpillar 312D2 excavator has won wide acclaim in the market for its outstanding performance and reliable durability. The working time of this device is only 6,000 hours, which means it is still in good operating condition and has a long service life. It is equipped with a Caterpillar C4.4ACERT engine, which is a power unit that meets Tier 3 emission standards, with a maximum output power of up to 75 horsepower (55 kilowatts), ensuring high efficiency and energy conservation while providing strong power support. In terms of the hydraulic system, the 312D2 is equipped with an advanced combination of variable displacement piston pumps and motors. This design not only enhances the excavation efficiency but also significantly reduces fuel consumption. In addition, through the optimized hydraulic control valve group, the operator can more precisely control the movement of the robotic arm, thereby meeting the requirements of fine operations under complex working conditions. As a medium-sized excavator, the Caterpillar 312D2 features outstanding flexibility and stability, making it suitable for various earthwork projects, road construction, and mining scenarios. Its cab design fully takes into account the driver's comfort. The s
| Specifications | Value |
|---|---|
| No. | 976021 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12920 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 2800 |
| Rod length (mm) | 3000 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C4.2ACERT |
| Rated power (kw/rpm) | 72/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 4.25 |
| Rotation speed (rpm) | 12.4 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 96 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 3.4/5.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.3 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.05 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162(including fuel tank) |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2970 |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2780 |
| Maximum digging depth (mm) | 5840 |
| Maximum excavation height (mm) | 8580 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 5160 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8430 |
| Maximum effective digging depth (mm) | 5640 |
Overview
No.976021
Brand Name:
CaterpillarModel Number:
312DYear:
2014
Location:
Yunnan China
