2016 Caterpillar 312D








Product Description
We currently have multiple second-hand Caterpillar 312D excavators, offering both direct injection and electronic injection power system options to meet the demands of various working conditions. These devices have been meticulously maintained, with an average working time of approximately 4,000 hours, ensuring good mechanical condition and a long service life. In terms of power, the Caterpillar 312D is equipped with an efficient Cat C4.4 engine, with a maximum power output of 75 kilowatts (101 horsepower). Whether it is a direct injection or electronic injection version, it can provide strong and stable power output, and at the same time has excellent fuel economy. The advanced emission control system complies with strict environmental protection standards and reduces the impact on the environment. In terms of the hydraulic system, this model is equipped with a high-performance variable displacement pump and multiple high-quality hydraulic motors, enabling rapid response and smooth operation. Its maximum digging force reaches an astonishing 69 kilonewtons. Coupled with the spacious and comfortable cab design, it can easily complete the operation tasks even in complex terrains. As a medium-sized excavator, the Caterpillar 312D has w
| Specifications | Value |
|---|---|
| No. | 977717 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12920 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 2800 |
| Rod length (mm) | 3000 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C4.2ACERT |
| Rated power (kw/rpm) | 72/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 4.25 |
| Rotation speed (rpm) | 12.4 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 96 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 3.4/5.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.3 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.05 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162(including fuel tank) |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2970 |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2780 |
| Maximum digging depth (mm) | 5840 |
| Maximum excavation height (mm) | 8580 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 5160 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8430 |
| Maximum effective digging depth (mm) | 5640 |
Overview
No.977717
Brand Name:
CaterpillarModel Number:
312DYear:
2016
Location:
Guangdong China
