2015 Caterpillar 315DL










| Specifications | Value |
|---|---|
| No. | 964883 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17280 |
| Bucket capacity (m³) | 0.61 |
| Boom length (mm) | 5100 |
| Rod length (mm) | 2250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT C4.2 ACERT |
| Rated power (kw/rpm) | 91 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 40.7 |
| Rotation speed (rpm) | 10.2 |
| Travel speed (km/h) | 5.6 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 22.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 150 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-100 x 1048 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-120 x 1331 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-110 x 1193 |
| Fuel Tank (L) | 300 |
| Hydraulic Tank (L) | 106 |
| Engine Oil changes (L) | 17.5 |
| Coolant (L) | 22 |
| Hydraulic System (L) | 190 |
| Total transport length (mm) | 8520 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2930 |
| Full cab height (mm) | 2870 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 460 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 3170 |
| Maximum digging depth (mm) | 5720 |
| Maximum excavation height (mm) | 8740 |
| Maximum unloading height (mm) | 6140 |
| Maximum vertical digging depth (mm) | 4920 |
| Maximum excavation radius of stop surface (mm) | 8430 |
Description
【 Premium Recommendation 】 Second-hand Caterpillar 315D2L excavator This second-hand Caterpillar 315D2L excavator has a working time of only 1,800 hours. Its performance is quite stable, the work is coordinated and full of energy. The entire machine has undergone strict testing and maintenance to ensure that every detail is in the best condition. The large parts do not leak oil, and the overall quality of the vehicle is guaranteed. In terms of the power system, this aircraft is equipped with a Caterpillar C4.4ACERT engine, with a maximum power output of 95kW (127 horsepower), meeting the Tier 3 emission standards. The powerful output combined with efficient fuel economy enables this excavator to maintain outstanding working efficiency under various working conditions. Whether it is excavation, loading or crushing operations, they can all be handled with ease. The hydraulic system is a major highlight of the Caterpillar 315D2L. The advanced CLSS closed center load sensing hydraulic system is adopted, which responds quickly and operates smoothly, ensuring the flexibility and stability of the equipment in complex environments. Meanwhile, the application of intelligent control technology enables machines to automatically adjust the pump
Overview
No.964883
Brand Name:
CaterpillarModel Number:
315DLYear:
2015
Location:
Peking China
