2016 Caterpillar 320C






| Specifications | Value |
|---|---|
| No. | 963525 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Description
Second-hand Caterpillar 320C excavator This second-hand Caterpillar 320C excavator has been in use since 2010, with a cumulative working time of only 5,000 hours. The overall condition of the vehicle is good and it is well maintained. As a medium-sized excavator, it is widely used in multiple fields such as earthwork, construction, and mining. Its power system adopts Caterpillar's own C6.4 engine. This straight-six turbocharged diesel engine not only has strong power (with a maximum output power of up to 140 horsepower), but also has excellent fuel economy, which can ensure efficient operation while reducing operating costs. In terms of the hydraulic system, the 320C adopts advanced negative flow control technology, ensuring the accuracy and response speed of operation, while effectively reducing energy loss and improving work efficiency. In addition, this model is also equipped with an intelligent electronic control system that can automatically adjust the pump displacement according to the actual load, further optimizing the overall performance of the machine. Considering its outstanding overall performance and relatively short working hours, the reasonable quoted price for such a well-conditioned second-hand Caterpillar 320C exca
Overview
No.963525
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangxi China
