2016 Caterpillar 320C










| Specifications | Value |
|---|---|
| No. | 966044 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Description
Second-hand Caterpillar 320C excavator We recommend to you this second-hand Caterpillar 320C excavator with outstanding performance and extremely high cost performance. This equipment has an excellent working record, with a cumulative working time of only 6,500 hours, which is of medium usage intensity. The mechanical condition is maintained very well, making it suitable for various working conditions. In terms of the power system, the Caterpillar 320C is equipped with a powerful and reliable Cat C7 engine, which is renowned for its excellent fuel economy and strong torque output. It ensures efficient operation while effectively reducing operating costs. In addition, it also features excellent cold start performance, enabling it to quickly enter the working state even in cold environments. The hydraulic system is another major highlight of this excavator. It adopts advanced load sensing technology, which can automatically adjust the oil volume according to the actual operation requirements, ensuring smooth and fluid operation while reducing energy loss. Whether it is excavation, loading or crushing operations, it can demonstrate excellent maneuverability and stability. It is worth mentioning that this excavator not only has an affo
Overview
No.966044
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Yunnan China
