2016 Caterpillar 320C








| Specifications | Value |
|---|---|
| No. | 966811 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Description
Second-hand Caterpillar 320C excavator This second-hand Caterpillar 320C excavator is an indispensable and capable assistant for you in various construction environments. It has over 60,000 hours of working time, demonstrating its outstanding durability and reliability. Despite having been in use for a long time, the machine has been carefully maintained and inspected by our professional team, ensuring its good condition and ready for operation at any time. In terms of the power system, this machine is equipped with the original imported C7 engine from Caterpillar. This engine is renowned for its powerful output and smooth operation, maintaining efficient and stable performance even under harsh working conditions. Meanwhile, advanced fuel injection technology leads to lower fuel consumption and effective control of operating costs. The hydraulic system adopts a closed central circuit design independently developed by Caterpillar, featuring a fast response speed, flexible and accurate operation. It can handle various operations such as excavation, loading and crushing with ease. In particular, it is equipped with a large-capacity water tank, which can effectively enhance heat dissipation efficiency, extend continuous operation time,
Overview
No.966811
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangdong China
