2016 Caterpillar 320C











| Specifications | Value |
|---|---|
| No. | 968885 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Description
【 Premium Recommendation 】 Caterpillar 320C Excavator. This machine is an excellent choice for personal use on the site. Its appearance is well maintained, and the original painted body still retains the bright luster when it left the factory. The large rear design is not only aesthetically pleasing but also significantly enhances the stability and durability of the entire machine. The working time of this excavator is only a few thousand hours. For a second-hand device, such a usage frequency is at a very low level, which means it still has a long service life and good working condition. In terms of the power system, the Caterpillar 320C is equipped with an efficient and reliable engine. Even after long-term operation, it can maintain strong power output and a smooth operating experience. Whether it is excavation, loading or crushing operations, it can handle them with ease. The hydraulic system adopts advanced technical configuration, ensuring rapid and accurate response to actions. Even in the face of complex and changeable construction environments, it can complete tasks with ease. In addition, this model is equipped with a large water tank of increased capacity, which effectively extends the continuous operation time, reduces th
Overview
No.968885
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangdong China
