2016 Caterpillar 320C

1/9
Used Caterpillar 320C Excavator 2016 Model / 1
Used Caterpillar 320C Excavator 2016 Model / 2
Used Caterpillar 320C Excavator 2016 Model / 3
Used Caterpillar 320C Excavator 2016 Model / 4
Used Caterpillar 320C Excavator 2016 Model / 5
Used Caterpillar 320C Excavator 2016 Model / 6
Used Caterpillar 320C Excavator 2016 Model / 7
Used Caterpillar 320C Excavator 2016 Model / 8
Used Caterpillar 320C Excavator 2016 Model / 9

Product Description

【 On-site Special Offer 】 Premium Caterpillar 320C excavator, user benefits Not to be missed! We currently have a second-hand Caterpillar 320C excavator in excellent condition for sale. This is a classic model that has received wide acclaim in the market. Since its commissioning, the total working hours of this equipment have only been around 5,000 hours, which is far lower than the average service life of similar machines. This means that it still has a long service life waiting for you to explore. The power system of this excavator is equipped with an original imported Caterpillar engine, which is stable and reliable in performance, powerful and low in fuel consumption. It can maintain efficient operation even under harsh working conditions and handle both plain and mountainous operations with ease. In addition, its advanced hydraulic control system makes the operation more precise and smooth, greatly improving work efficiency and safety. There is no leakage in the hydraulic cylinder, pump or pipelines, ensuring the good operating condition of the entire system. The exterior of the vehicle body shows almost no damage or rust marks, and the internal structure is also very sturdy and durable. The cab is spacious and comfortable with

SpecificationsValue
No.971638
Tonnage (tons)20
Working weight (kg)21115
Bucket capacity (m³)0.8
Boom length (mm)5680
Rod length (mm)2900
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCaterpillar CAT 3066 ATAAC
Rated power (kw/rpm)110/1800
Cooling modewater-cooling
Cylinder diameter × stroke (mm)102 x 130
Displacement (L)6.4
Ground specific pressure (Kpa)48.02
Rotation speed (rpm)11.5
Bucket digging force (kN)132
Rod digging force (kN)99
Travel speed (km/h)5.5
Maximum flow of main pump (l/min)205
Traveling Hydraulic Circuit (Mpa)34.4
Rotary Hydraulic Circuit (Mpa)26
Working Hydraulic Circuit (Mpa)34.3
Pilot Oil Circuit (MPa)4.12
Bucket cylinders - Number × diameter × stroke (mm)1-120 x 1030
Bucket rod cylinders - Number × diameter × stroke (mm)1-140 x 1430
Boom cylinders - Number × diameter × stroke (mm)2-120 x 1260
Fuel Tank (L)320
Hydraulic Tank (L)120
Engine Oil changes (L)30
Coolant (L)24
Hydraulic System (L)200
Total transport length (mm)9390
Total transport width (mm)2800
Total transport height (mm)3050
Full cab height (mm)3050
Minimum ground clearance (mm)460
Back end turning radius (mm)2770
Total track length (mm)4070
Track gauge (mm)2200
Track plate width (mm)600
Total track width (mm)2800
Track ground length (mm)3260
Maximum digging depth (mm)6550
Maximum excavation height (mm)9440
Maximum unloading height (mm)6770
Maximum vertical digging depth (mm)5440
Maximum excavation radius of stop surface (mm)9710
see more

Overview

No.971638

Brand Name:

Caterpillar

Model Number:

320C

Year:

2016

Location:

Fujian China
