2016 Caterpillar 320C











Product Description
This Caterpillar 320C excavator, with its outstanding performance and economical price, has become a highly favored choice in the market. This equipment is equipped with a large-capacity water tank, ensuring good cooling effect during long-term high-intensity operation and effectively extending the engine's lifespan. The working time/usage hours are expected to be around 4,000 hours, indicating that it is in a relatively ideal usage state and suitable for various engineering requirements. In terms of power, this machine is equipped with Caterpillar's self-developed C7.1 inline six-cylinder turbocharged diesel engine, with a maximum output power of up to 140kW (approximately 190 horsepower). It not only provides strong power support but also ensures fuel economy. In addition, the advanced electronic control system enables the engine to automatically adjust its speed according to the actual load, further reducing fuel consumption. In terms of the hydraulic system, a combination of variable plunger pumps and high-efficiency hydraulic motors is adopted, ensuring smooth operation and rapid response of the entire machine. Whether it is excavation, loading or crushing operations, they can all be handled with ease. It is particularly worth m
| Specifications | Value |
|---|---|
| No. | 977567 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Overview
No.977567
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangdong China
