2016 Caterpillar 320C








Product Description
This second-hand Caterpillar 320C excavator, equipped with a large-capacity water tank, is your ideal choice for various construction environments. The total working time of the equipment is only XX hours (the exact usage hours need to be confirmed based on the actual situation), ensuring its good mechanical condition and long service life. In terms of the power system, this excavator is equipped with an original Caterpillar engine, model XXX (the specific model needs to be confirmed based on the actual situation), which features strong power output and smooth operation performance, ensuring high working efficiency. In addition, this engine also features excellent fuel economy, reducing operating costs. The hydraulic system adopts an advanced combination of hydraulic pumps and motors, providing powerful digging force and precise operation control. The hydraulic pump may be designed as a variable plunger pump, which can automatically adjust the flow rate according to the actual working conditions, thereby achieving the best working efficiency. The hydraulic motor is expected to be of gear or plunger type, ensuring smooth operation and rapid response. As a high-performance construction machinery, this machine not only features a sturd
| Specifications | Value |
|---|---|
| No. | 978733 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Overview
No.978733
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangxi China
