2016 Caterpillar 320C











Product Description
Welcome to test drive this nearly brand-new Caterpillar 320C excavator. It works for only single-digit hours and has hardly been used before. This device is equipped with an efficient Caterpillar C7.1 ACERT engine with a rated power of 140 kilowatts (approximately 190 horsepower), ensuring strong power output and excellent fuel efficiency. The advanced hydraulic system is equipped with a high-quality combination of variable piston pumps and hydraulic motors, which can provide a stable and precise operation experience. Whether it is excavation, loading or other complex operations, it can handle them with ease. The main advantages of the Caterpillar 320C excavator include: Firstly, its outstanding durability and reliability are attributed to the high-standard manufacturing processes that the Caterpillar brand has always adhered to; Secondly, this model features a spacious and comfortable cab design, equipped with an air conditioning system and adjustable seats, which greatly enhances the operator's comfort. Thirdly, its maintenance and upkeep are simple and quick, and the easily accessible service points reduce downtime. In addition, this excavator model is equipped with an intelligent control system that supports multiple working mode
| Specifications | Value |
|---|---|
| No. | 978975 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Overview
No.978975
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangdong China
