2021 Caterpillar 320DGC
Product Description
Built for demanding construction environments, this 2021 Caterpillar 320DGC delivers proven performance with 20-ton capacity and robust C6.4 ACERT engine technology. Operating at 92.3kW rated power, this excavator handles heavy-duty applications with 140.1kN bucket digging force and 0.9m³ bucket capacity.
Caterpillar's reputation for reliability translates directly into lower ownership costs and superior resale value. With extensive dealer networks across China and globally available parts inventory, maintenance downtime stays minimal. Joint venture manufacturing ensures quality standards while providing cost-effective operation.
- Maximum digging depth: 6,710mm with 9,840mm reach height
- Hydraulic system: 205L/min main pump flow for responsive operation
- Transport dimensions: 9,460mm length, ready for immediate deployment
- Fuel efficiency: 410L tank capacity with water-cooled engine
Located in Anshun, Guizhou Province, this machine represents solid investment potential. Caterpillar's established service infrastructure and parts availability make this 320DGC a smart choice for contractors prioritizing operational reliability and long-term value retention.
| Specifications | Value |
|---|---|
| No. | 986057 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20400 |
| Bucket capacity (m³) | 0.9 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C6.4ACERT |
| Rated power (kw/rpm) | 92.3/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.37 |
| Ground specific pressure (Kpa) | 6 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 140.1 |
| Rod digging force (kN) | 106.4 |
| Travel speed (km/h) | 3.5/5.7 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1104 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1504 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 25 |
| Hydraulic System (L) | 260 |
| Total transport length (mm) | 9460 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1020 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4075 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3265 |
| Maximum digging depth (mm) | 6710 |
| Maximum excavation height (mm) | 9840 |
| Maximum unloading height (mm) | 6500 |
| Maximum vertical digging depth (mm) | 6180 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 9850 |
| Maximum effective digging depth (mm) | 6540 |
Overview
No.986057
Brand Name：
CaterpillarModel Number：
320DGCYear：
2021
Location：
Guizhou China
