2014 Caterpillar 323D2L

1/8
Used Caterpillar 323D2L Excavator 2014 Model / 1
Used Caterpillar 323D2L Excavator 2014 Model / 2
Used Caterpillar 323D2L Excavator 2014 Model / 3
Used Caterpillar 323D2L Excavator 2014 Model / 4
Used Caterpillar 323D2L Excavator 2014 Model / 5
Used Caterpillar 323D2L Excavator 2014 Model / 6
Used Caterpillar 323D2L Excavator 2014 Model / 7
Used Caterpillar 323D2L Excavator 2014 Model / 8

Product Description

There is currently a second-hand Caterpillar 323D2L excavator manufactured at the end of 2014, with an estimated working time of about 5,000 hours. It has undergone a comprehensive annual inspection to ensure that the equipment is in good condition and has stable performance. This excavator is equipped with a Caterpillar C7.1 inline six-cylinder turbocharged engine, with a maximum output power of up to 110kW, providing strong power support while ensuring excellent fuel economy. In terms of the hydraulic system, an advanced variable piston pump combined with an efficient hydraulic motor is adopted, which can achieve precise and rapid operation response. Whether it is excavation, loading or crushing operations, it can handle them with ease. In addition, the 323D2L is equipped with an intelligent electronic control system that can automatically adjust the power distribution according to the actual working conditions, further enhancing work efficiency while reducing energy consumption. The appearance of this machine is well-preserved, "original and authentic", without any unofficial modification or refurbishment. It retains all the advantages of the original design by Caterpillar. Its robust and durable structural design, combined with a

SpecificationsValue
No.974211
Tonnage (tons)23
Working weight (kg)23300
Bucket capacity (m³)1.19
Boom length (mm)5700
Rod length (mm)2900
Country of originJapan
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCat C7.1 ACERT
Rated power (kw/rpm)118/1100
Cylinder diameter × stroke (mm)105 x 135
Number of cylinders (PCS)6
Displacement (L)7.01
Rotation speed (rpm)10.5
Climbing ability (%)70/35 °
Bucket digging force (kN)140
Rod digging force (kN)107
Maximum tractive force (kN)205
Travel speed (km/h)Low: 3.5 / High: 5.6
Turning torque (Nm)61.8
Main overflow set pressure (Mpa)35
Maximum flow of main pump (l/min)214 x 2
Traveling Hydraulic Circuit (Mpa)35
Rotary Hydraulic Circuit (Mpa)25
Hydraulic crushing pipeline is standardno
Working Hydraulic Circuit (Mpa)35
Pilot Oil Circuit (MPa)3.92
Pilot pump flow (L/min)23.1
Bucket cylinders - Number × diameter × stroke (mm)120 x 1104
Bucket rod cylinders - Number × diameter × stroke (mm)140 x 1504
Boom cylinders - Number × diameter × stroke (mm)120 x 1260
Fuel Tank (L)410
Hydraulic Tank (L)138
Engine Oil changes (L)22
Coolant (L)25
Hydraulic System (L)260(including fuel tank)
Total transport length (mm)9460
Total transport width (mm)2980
Total transport height (mm)3030
Full cab height (mm)2950
Counterweight ground clearance (mm)1020
Minimum ground clearance (mm)450
Back end turning radius (mm)2750
Onboard width (mm)2740
Total track length (mm)4455
Track gauge (mm)2380
Track plate width (mm)600
Total track width (mm)3180
Track ground length (mm)3650
Maximum digging depth (mm)6720
Maximum excavation height (mm)9490
Maximum unloading height (mm)6490
Maximum vertical digging depth (mm)5690
Bulldozer lift or depth (mm)No bulldozer
Dodging plate width × height (mm)No bulldozer
Maximum excavation radius of stop surface (mm)9860
Maximum effective digging depth (mm)6380
see more

Overview

No.974211

Brand Name:

Caterpillar

Model Number:

323D2L

Year:

2014

Location:

Jiangsu China
