2016 Caterpillar 324D
| Specifications | Value |
|---|---|
| No. | 964689 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 24240 |
| Bucket capacity (m³) | 1 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 2950 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7 ACERT |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 24.5 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1104 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300(including fuel tank) |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3450 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
Description
"Caterpillar 324D Second-hand excavator This second-hand Caterpillar 324D excavator is priced at 79,800 yuan and offers an extremely high cost performance. The total working time of this machine is 4,500 hours, and it is in good working condition, suitable for various medium and small-sized engineering operations. The whole machine has a compact structure and flexible operation, making it especially suitable for construction needs in narrow urban Spaces. In terms of the power system, it adopts the original Caterpillar C4.4 engine, with a rated power of 119 kilowatts (approximately 160 horsepower). While providing strong power, its fuel economy is also well guaranteed. Whether it is excavation, loading or crushing operations, they can all be handled with ease. In addition, this engine also features low emissions and meets environmental protection requirements. It can operate normally even in the city center areas where there are strict restrictions on exhaust emissions. The hydraulic system is a major highlight of this machine. It adopts the advanced CLSS closed center load sensing system, which can automatically adjust the oil volume according to the actual load to ensure smooth and efficient operation. Meanwhile, it is equipped wit
Overview
No.964689
Brand Name：
CaterpillarModel Number：
324DYear：
2016
Location：
Fujian China
