2016 Caterpillar 324D
| Specifications | Value |
|---|---|
| No. | 967037 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 24240 |
| Bucket capacity (m³) | 1 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 2950 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7 ACERT |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 24.5 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1104 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300(including fuel tank) |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3450 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
Description
"Caterpillar 324D Second-hand excavator Dear friends in the engineering field, today we bring you a second-hand excavator with an extremely high cost performance - the Caterpillar 324D. This machine is a powerful member of the Caterpillar family and enjoys a high reputation in the industry for its outstanding performance and reliability. For those friends who are looking for a second-hand excavator that is efficient, durable and reasonably priced, this is definitely a great opportunity not to be missed. 【 Basic Information - Working hours: The cumulative working time of this machine is approximately 4,000 hours, which is in the golden stage of the mechanical life cycle. This not only ensures the maturity of the equipment but also avoids potential problems caused by excessive use. - Power System: It is equipped with Caterpillar's own produced C4.4 engine. This inline four-cylinder turbocharged diesel engine not only has strong power (with a maximum output power of up to 110kW), but also has excellent fuel economy. It can ensure efficient operation while effectively reducing operating costs. - Hydraulic system: It adopts an advanced closed center load sensing hydraulic system, which can automatically adjust the flow distribution accord
Overview
No.967037
Brand Name：
CaterpillarModel Number：
324DYear：
2016
Location：
Guangdong China
