2018 Caterpillar 326DL

1/9
Used Caterpillar 326DL Excavator 2018 Model / 1
Used Caterpillar 326DL Excavator 2018 Model / 2
Used Caterpillar 326DL Excavator 2018 Model / 3
Used Caterpillar 326DL Excavator 2018 Model / 4
Used Caterpillar 326DL Excavator 2018 Model / 5
Used Caterpillar 326DL Excavator 2018 Model / 6
Used Caterpillar 326DL Excavator 2018 Model / 7
Used Caterpillar 326DL Excavator 2018 Model / 8
Used Caterpillar 326DL Excavator 2018 Model / 9

Product Description

【 Premium Recommendation 】2018 Model Caterpillar 326D2L mining-specific excavator, with outstanding performance, available in stock! Since this excavator was put into use in 2018, its cumulative working time has only been 4,500 hours, far lower than the average service life of similar equipment, ensuring the machine's good condition and a relatively long remaining service life. It is equipped with a Caterpillar C7.1 ACERT engine, which is powerful and highly fuel-efficient, with a maximum output power of up to 192 kilowatts (approximately 258 horsepower), providing stable and reliable power support under various working conditions. In addition, this model is also equipped with an advanced hydraulic system, including an efficient combination of the main pump and control valves, which can achieve rapid response and smooth operation. Whether it is excavation, loading or crushing operations, it can handle them with ease. More importantly, as a model specifically designed for mines, it features robust and durable structural components and a chassis, with a particularly enhanced adaptability to harsh environments, making it highly suitable for high-intensity and long-duration work requirements. Purchase now and enjoy discounted prices and pr

SpecificationsValue
No.971217
Tonnage (tons)26
Working weight (kg)25560
Bucket capacity (m³)1.35/1.57
Boom length (mm)5300/5900
Rod length (mm)2000/2500/2950
Country of originXuzhou, Jiangsu
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCaterpillar C7 ACERT
Rated power (kw/rpm)140
Cooling modewater-cooling
Cylinder diameter × stroke (mm)110 x 127
Displacement (L)7.2
Rotation speed (rpm)9.6
Bucket digging force (kN)174
Rod digging force (kN)122
Maximum tractive force (kN)227
Travel speed (km/h)5.5
Turning torque (Nm)73.4
Main overflow set pressure (Mpa)35
Rotary hydraulic motor type24.5
Type of walking hydraulic motor35
Maximum flow of main pump (l/min)235
Pilot Oil Circuit (MPa)3.9
Bucket cylinders - Number × diameter × stroke (mm)1 x 150 x 1156
Bucket rod cylinders - Number × diameter × stroke (mm)1 x 140 x 1660
Boom cylinders - Number × diameter × stroke (mm)2 x 135 x 1305
Fuel Tank (L)520
Hydraulic Tank (L)145
Engine Oil changes (L)30
Coolant (L)30
Hydraulic System (L)300
Total transport length (mm)10060
Total transport width (mm)3390
Total transport height (mm)3170
Full cab height (mm)2980
Counterweight ground clearance (mm)1060
Minimum ground clearance (mm)470
Back end turning radius (mm)2940
Total track length (mm)4630
Track gauge (mm)2590
Track plate width (mm)600
Total track width (mm)3390
Maximum digging depth (mm)6740
Maximum excavation height (mm)9660
Maximum unloading height (mm)6700
Maximum vertical digging depth (mm)5830
Maximum excavation radius of stop surface (mm)10030
Maximum effective digging depth (mm)6560
see more

Overview

No.971217

Brand Name:

Caterpillar

Model Number:

326DL

Year:

2018

Location:

Jiangsu China
