2016 Caterpillar 329D
| Specifications | Value |
|---|---|
| No. | 965614 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Description
【 Premium Recommendation 】 The top-quality Caterpillar 329D excavator is now priced at 118,000 yuan, offering an extremely high cost performance. It is your ideal choice for engineering operations. This equipment has a working time of 6,000 hours, with stable overall performance, proper maintenance, clean appearance, and no major accident records. It is suitable for construction needs under various complex working conditions. In terms of the power system, this machine is equipped with a Caterpillar C7 ACERT engine, with a maximum power output of 192kW (257 horsepower). It not only has strong power but also excellent fuel economy, effectively reducing operating costs. In addition, this engine also adopts advanced emission control technology, meeting national environmental protection standards, making your construction greener and more low-carbon. The hydraulic system adopts a high-pressure common rail pump and valve body combination developed by Caterpillar itself, ensuring smooth and precise operation of the entire machine, rapid and sensitive response. Whether it is excavation or loading, it can handle it with ease. Its outstanding handling performance enables drivers to complete tasks more efficiently, enhancing productivity while
Overview
No.965614
Brand Name：
CaterpillarModel Number：
329DYear：
2016
Location：
Fujian China
