2016 Caterpillar 329D









| Specifications | Value |
|---|---|
| No. | 966540 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Description
【 Carter 329D Second-hand Excavator This second-hand Caterpillar 329D excavator is a highly favored medium-sized excavator in the market, featuring outstanding performance and reliability. This equipment has a cumulative working time of 4,500 hours and is in good working condition, suitable for various working conditions. It is equipped with a powerful C7 ACERT engine, with a maximum power output of 168kW (225 horsepower), ensuring efficient power output and low fuel consumption performance, and maintaining stable operation even in harsh environments. Meanwhile, the advanced electronic control system can intelligently adjust the engine speed, further optimizing fuel economy. Its hydraulic system adopts Caterpillar's unique CLSS closed center load sensing system, which features fast response speed and flexible and precise operation. Whether it is excavation, loading or crushing operations, they can all be handled with ease, demonstrating outstanding work efficiency. In addition, the spacious and comfortable cab design provides an excellent operating field of vision. The sturdy and durable structural components ensure a long service life. In conclusion, this Caterpillar 329D not only boasts powerful performance and efficient hydraulic
Overview
No.966540
Brand Name:
CaterpillarModel Number:
329DYear:
2016
Location:
Guangdong China
