2016 Caterpillar 336FLH







| Specifications | Value |
|---|---|
| No. | 968770 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
Description
【 Premium Recommendation 】 Second-hand Caterpillar 336D excavator, now priced at only 130,000 yuan! This device is not only affordable in price but also has excellent performance, making it an ideal choice for your engineering work. This excavator has a working time of only 4,000 hours, which is equivalent to a moderately used machine. However, its overall condition is very good and it is well maintained, with almost no signs of wear and tear visible. In terms of power, this 336D is equipped with an original imported C9 ACERT engine from Caterpillar, with a maximum output power of up to 225kW (approximately 302 horsepower), featuring excellent fuel economy and reliability. It can maintain stable operation even in harsh working environments and meet the demands of various high-intensity operations. In addition, this model is also equipped with an advanced electronic control system that can automatically adjust the engine speed and torque according to the actual working conditions, thereby achieving a balance between the best working efficiency and the lowest fuel consumption. In terms of the hydraulic system, the 336D adopts high-pressure common rail technology and negative flow control mode, ensuring flexible operation and rapid resp
Overview
No.968770
Brand Name:
CaterpillarModel Number:
336FLHYear:
2016
Location:
Sichuan China
