2014 Caterpillar 340DL
| Specifications | Value |
|---|---|
| No. | 968303 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38100-38600 |
| Bucket capacity (m³) | 1.88/2.14 |
| Boom length (mm) | 6500/6180 |
| Rod length (mm) | 2550/2800/3200 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 ACERT |
| Rated power (kw/rpm) | 209 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 176 |
| Rod digging force (kN) | 158 |
| Travel speed (km/h) | 5 |
| Maximum flow of main pump (l/min) | 2 x 280 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 310 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3520 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3420 |
| Counterweight ground clearance (mm) | 1500 |
| Minimum ground clearance (mm) | 743 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5066 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3520 |
| Maximum digging depth (mm) | 7322 |
| Maximum excavation height (mm) | 10550 |
| Maximum unloading height (mm) | 7277 |
| Maximum vertical digging depth (mm) | 5712 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11084 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7035 |
Description
【 Premium Recommendation 】 The 2014 Caterpillar 340D2 excavator, with outstanding performance and excellent condition, is your reliable assistant for engineering operations. Since its manufacture, this machine has been working for only about 6,000 hours. For a second-hand device, this service life is very ideal, indicating that it still has a long service life and good working condition. In terms of the power system, this machine is equipped with a Caterpillar C7.1 inline six-cylinder turbocharged diesel engine, with a maximum power output of up to 242kW (approximately 325 horsepower). It not only offers strong power but also has excellent fuel economy, capable of meeting the demands of various complex working conditions. More importantly, this engine has undergone strict emission tests and meets the latest environmental protection standards, allowing you to enjoy efficient operation while also contributing to environmental protection. The hydraulic system adopts Caterpillar's advanced CLSS closed center load sensing system, which responds quickly and operates precisely. Whether it is excavation, loading or crushing operations, it can handle them with ease. In addition, its outstanding stability and reliability have also received hig
Overview
No.968303
Brand Name：
CaterpillarModel Number：
340DLYear：
2014
Location：
Shandong China
