2014 Caterpillar 340DL







| Specifications | Value |
|---|---|
| No. | 970463 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38100-38600 |
| Bucket capacity (m³) | 1.88/2.14 |
| Boom length (mm) | 6500/6180 |
| Rod length (mm) | 2550/2800/3200 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 ACERT |
| Rated power (kw/rpm) | 209 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 176 |
| Rod digging force (kN) | 158 |
| Travel speed (km/h) | 5 |
| Maximum flow of main pump (l/min) | 2 x 280 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 310 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3520 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3420 |
| Counterweight ground clearance (mm) | 1500 |
| Minimum ground clearance (mm) | 743 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5066 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3520 |
| Maximum digging depth (mm) | 7322 |
| Maximum excavation height (mm) | 10550 |
| Maximum unloading height (mm) | 7277 |
| Maximum vertical digging depth (mm) | 5712 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11084 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7035 |
Description
【 Premium Recommendation 】 The 2014 Caterpillar 340D2 excavator is now priced at 170,000 yuan. This equipment has only been in operation for 5,000 hours since leaving the factory and is in the best working condition. It is well maintained and has stable and reliable performance. As one of the world's leading manufacturers of construction machinery, Caterpillar is renowned for the outstanding quality and durability of its products, and this 340D2 is a prime example among them. In terms of the power system, it is equipped with the C9.3 ACERT engine independently developed by Caterpillar. This engine not only has strong power but also high fuel efficiency, capable of meeting the operational requirements under various complex working conditions. More importantly, this engine adopts advanced emission control technology and meets environmental protection standards, making your construction greener and more low-carbon. The hydraulic system is a major highlight of this machine. It adopts Caterpillar's unique closed Center load sensing hydraulic system (CLSS), which responds quickly and operates precisely. Whether it is digging or loading, it can handle it with ease. In addition, this system also has a good energy-saving effect, effectively r
Overview
No.970463
Brand Name:
CaterpillarModel Number:
340DLYear:
2014
Location:
Yunnan China
