2014 Caterpillar 340DL






Product Description
This 2014 Caterpillar 340 excavator is a medium to large-sized excavator that has received high praise in the market. It has a working history of over 10 years, yet still maintains an excellent working condition. Currently, its price is around 100,000 yuan, offering a very high cost performance. The cumulative working time of this machine is approximately 7,000 hours, which is an ideal figure for a device that has been in service for nearly a decade, indicating that its usage frequency is moderate and it is well maintained. The Caterpillar 340 is equipped with a powerful and reliable C9.3 ACERT engine, which is renowned for its outstanding fuel efficiency and low emission characteristics. It can provide up to 328 horsepower in power output, ensuring that the machine can maintain efficient and stable operation under various complex working conditions. In addition, this model adopts an advanced hydraulic system design, which combines an efficient variable pump with load sensing technology. This not only enhances the operational response speed and smoothness but also significantly reduces energy consumption. This optimized hydraulic configuration makes the entire machine more flexible and at ease when performing tasks such as excavation
| Specifications | Value |
|---|---|
| No. | 971432 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38100-38600 |
| Bucket capacity (m³) | 1.88/2.14 |
| Boom length (mm) | 6500/6180 |
| Rod length (mm) | 2550/2800/3200 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 ACERT |
| Rated power (kw/rpm) | 209 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 176 |
| Rod digging force (kN) | 158 |
| Travel speed (km/h) | 5 |
| Maximum flow of main pump (l/min) | 2 x 280 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 310 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3520 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3420 |
| Counterweight ground clearance (mm) | 1500 |
| Minimum ground clearance (mm) | 743 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5066 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3520 |
| Maximum digging depth (mm) | 7322 |
| Maximum excavation height (mm) | 10550 |
| Maximum unloading height (mm) | 7277 |
| Maximum vertical digging depth (mm) | 5712 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11084 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7035 |
Overview
No.971432
Brand Name:
CaterpillarModel Number:
340DLYear:
2014
Location:
Fujian China
