2016 Caterpillar 390FLME






| Specifications | Value |
|---|---|
| No. | 964499 |
| Tonnage (tons) | 90 |
| Working weight (kg) | 92020 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cat C18 ACERT |
| Rated power (kw/rpm) | 391 |
| Cylinder diameter × stroke (mm) | 145 x 183 |
| Displacement (L) | 18.1 |
| Rotation speed (rpm) | 6.2 |
| Turning torque (Nm) | 590 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | Equipment: 952; Driving: 1064 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 4.0-4.4 |
| Pilot pump flow (L/min) | 67 |
| Bucket cylinders - Number × diameter × stroke (mm) | Hb2-series bucket cylinder diameter × stroke: 200×1451; Jc-series bucket cylinder diameter × stroke: 220×1586 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | Cylinder diameter × stroke: 220×2262 |
| Boom cylinders - Number × diameter × stroke (mm) | Cylinder diameter × stroke: 210×1967 |
| Fuel Tank (L) | 1240 |
| Hydraulic Tank (L) | 813 |
| Engine Oil changes (L) | 60 |
| Coolant (L) | 74 |
| Hydraulic System (L) | 997 |
Description
【 Premium Caterpillar 390 excavators, five units in stock for your selection! 】" We currently have five Caterpillar 390 large excavators, all of which are carefully selected high-quality second-hand equipment, waiting for your discerning eye to recognize them. This batch of Model 390 machines were all produced between 2015 and 2018, with an average working time of 4,000 to 6,000 hours. They are in the best working condition and are highly suitable for various civil engineering, mining and large-scale infrastructure construction projects. "Strong power Each Caterpillar 390 is equipped with a C18 ACERT engine. This high-performance engine not only has abundant power (with a maximum output power of up to 470kW/630 horsepower), but also has high fuel efficiency, effectively reducing operating costs. In addition, it is also equipped with an advanced electronic control system, ensuring smooth and reliable operation. "High-efficiency hydraulics This series of excavators adopts Caterpillar's unique CLSS closed center load sensing system, combined with high-pressure common rail technology, making the overall operation of the machine more sensitive and smooth. Both its digging power and lifting capacity far exceed those of products of the sam
Overview
No.964499
Brand Name:
CaterpillarModel Number:
390FLMEYear:
2016
Location:
Guangdong China
