2016 Caterpillar CT16
| Specifications | Value |
|---|---|
| No. | 966213 |
| Tonnage (tons) | 16 |
| Working weight (kg) | 17600 |
| Bucket capacity (m³) | 0.65 |
| Boom length (mm) | 5100 |
| Rod length (mm) | 2600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.4 ACERT |
| Rated power (kw/rpm) | 89 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 105 x 127 |
| Displacement (L) | 4.4 |
| Working form | Meet EU Stage IIIB emission standards |
| Ground specific pressure (Kpa) | 49 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 111 |
| Rod digging force (kN) | 88 |
| Maximum tractive force (kN) | 156.2 |
| Travel speed (km/h) | 5.2 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 300 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 22.6 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Pilot pump flow (L/min) | 25.8 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 110 x 1039 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1331 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1193 |
| Fuel Tank (L) | 290 |
| Hydraulic Tank (L) | 106 |
| Engine Oil changes (L) | 13.5 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 190 |
| Total transport length (mm) | 8570 |
| Total transport width (mm) | 2520/2590/2690 (with different width tracks) |
| Total transport height (mm) | 3180 (to the top of the boom) |
| Full cab height (mm) | 2890 |
| Counterweight ground clearance (mm) | 1010 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2500 |
| Total track length (mm) | 3970 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500/600/700 |
| Total track width (mm) | 2520/2590/2690 |
| Maximum digging radius (mm) | 8910 |
| Maximum digging depth (mm) | 6090 |
| Maximum excavation height (mm) | 8920 |
| Maximum unloading height (mm) | 6280 |
| Maximum vertical digging depth (mm) | 4930 |
| Maximum excavation radius of stop surface (mm) | 8780 |
| Maximum effective digging depth (mm) | 5870 |
Description
【 Premium Recommendation 】 Second-hand Caterpillar 315C excavator, equipped with a 16-meter long arm, in super good condition and at an affordable price! This second-hand Caterpillar 315C excavator boasts outstanding performance and an extremely high cost-performance ratio. With a working time of only 4,500 hours, proper maintenance and excellent mechanical condition, it is an ideal choice for your construction projects. In terms of the power system, this excavator is equipped with an original imported C7 engine from Caterpillar, which is powerful, stable and reliable. Whether it is excavation, crushing or loading operations, they can all be handled with ease. In addition, this engine also features excellent fuel economy, significantly reducing operating costs. In terms of the hydraulic system, advanced negative flow control technology is adopted, featuring rapid response and flexible operation. Whether performing meticulous work in confined Spaces or moving quickly in open areas, it can perform exceptionally well. Meanwhile, after comprehensive inspection and maintenance by a professional team, it is ensured that there are no leakage problems at all, guaranteeing the efficient operation of the equipment. It is particularly worth m
Overview
No.966213
Brand Name：
CaterpillarModel Number：
CT16Year：
2016
Location：
Guangdong China
