2014 Caterpillar CT16
| Specifications | Value |
|---|---|
| No. | 968872 |
| Tonnage (tons) | 16 |
| Working weight (kg) | 17600 |
| Bucket capacity (m³) | 0.65 |
| Boom length (mm) | 5100 |
| Rod length (mm) | 2600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.4 ACERT |
| Rated power (kw/rpm) | 89 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 105 x 127 |
| Displacement (L) | 4.4 |
| Working form | Meet EU Stage IIIB emission standards |
| Ground specific pressure (Kpa) | 49 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 111 |
| Rod digging force (kN) | 88 |
| Maximum tractive force (kN) | 156.2 |
| Travel speed (km/h) | 5.2 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 300 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 22.6 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Pilot pump flow (L/min) | 25.8 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 110 x 1039 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1331 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1193 |
| Fuel Tank (L) | 290 |
| Hydraulic Tank (L) | 106 |
| Engine Oil changes (L) | 13.5 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 190 |
| Total transport length (mm) | 8570 |
| Total transport width (mm) | 2520/2590/2690 (with different width tracks) |
| Total transport height (mm) | 3180 (to the top of the boom) |
| Full cab height (mm) | 2890 |
| Counterweight ground clearance (mm) | 1010 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2500 |
| Total track length (mm) | 3970 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500/600/700 |
| Total track width (mm) | 2520/2590/2690 |
| Maximum digging radius (mm) | 8910 |
| Maximum digging depth (mm) | 6090 |
| Maximum excavation height (mm) | 8920 |
| Maximum unloading height (mm) | 6280 |
| Maximum vertical digging depth (mm) | 4930 |
| Maximum excavation radius of stop surface (mm) | 8780 |
| Maximum effective digging depth (mm) | 5870 |
Description
【 Premium Recommendation 】 Second-hand Caterpillar 336D2 excavator from 2014 is now on sale at an extremely discounted price of 165,000 yuan! This machine has only been in operation for 4,500 hours since its purchase and is in good overall condition with proper maintenance. As one of the star products in the Caterpillar family, the 336D2 has won wide recognition in the market for its outstanding performance and reliability. In terms of power, this aircraft is equipped with a Cat C9 ACERT engine, with a maximum power of up to 225kW (approximately 302 horsepower), meeting the National III emission standards. This engine not only offers powerful output but also boasts excellent fuel economy, maintaining stable and efficient operation even under heavy-load working conditions. In addition, an advanced electronic control system can monitor and adjust the working status of the engine in real time, ensuring the best performance while extending its service life. The hydraulic system is one of the important indicators for evaluating the quality of an excavator. The 336D2 adopts Cat's unique CLSS closed center load sensing system, combined with a high-pressure variable pump design, achieving rapid response and smooth operation. Whether it is in
Overview
No.968872
Brand Name：
CaterpillarModel Number：
CT16Year：
2014
Location：
Shanghai China
