Product Description
The Doosan DH150-9C excavator of 2018 is a reliable assistant in your engineering projects. This device has been in use for an estimated 4,000 hours or so and still maintains an excellent working condition. The Yanmar engine it is equipped with has a powerful output of 106 kilowatts, ensuring efficient and stable working performance. In terms of the hydraulic system, it is equipped with high-performance Kawasaki hydraulic pumps and motors, providing a smooth and precise operation experience for the entire machine. Doosan DH150-9C is designed with a focus on durability and reliability. It adopts advanced structural materials and technologies, which not only reduce maintenance costs but also extend its service life. In addition, the spacious and comfortable cab, intuitive and user-friendly operation interface, as well as the low-noise design, ensure a good working environment even during long periods of operation. Whether it's earthwork excavation or stone loading, this excavator can handle it with ease and is your ideal choice to enhance work efficiency.
| Specifications | Value |
|---|---|
| No. | 973171 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13850 |
| Bucket capacity (m³) | 0.53 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DL06 |
| Rated power (kw/rpm) | 74/1,900 |
| Cylinder diameter × stroke (mm) | 100*125 |
| Number of cylinders (PCS) | 6 |
| Working form | In-line turbocharging |
| Rotation speed (rpm) | 10.1rpm |
| Bucket digging force (kN) | 103 |
| Rod digging force (kN) | 61 |
| Travel speed (km/h) | 5.04 / 3.01 |
| Turning torque (Nm) | 3655 |
| Total transport length (mm) | 7662 |
| Total transport width (mm) | 2530 |
| Total transport height (mm) | 2476 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 7 |
| Maximum digging radius (mm) | 8305 |
| Maximum digging depth (mm) | 5625 |
| Maximum excavation height (mm) | 8750 |
| Maximum unloading height (mm) | 6300 |
| Maximum vertical digging depth (mm) | 4650 |
