Product Description
With a working weight of 5700 kg and a bucket capacity of 0.21 m³, this 2021 Doosan DX60-9C excavator is an ideal fleet addition for busy contractors. Powered by a D24C diesel engine, delivering 38.9 kW at 2100 rpm, it ensures reliable performance on any job site. Located in 山东临沂, this machine features a robust design with a maximum digging depth of 3807 mm and a digging force of 4.2 tons, making it perfect for a wide range of excavation tasks.
- Tonnage: 6 tons
- Boom length: 3000 mm
- Rod length: 1600 mm
- Travel speed: 4.2/2.3 km/h
- Maximum digging radius: 6136 mm
Equipped with an axial piston hydraulic motor and a variable piston pump, this excavator offers efficient and precise control. Its compact dimensions, including a total transport width of 2000 mm and height of 1983 mm, make it easy to maneuver and transport. Add this versatile and dependable Doosan DX60-9C to your fleet to enhance productivity and reliability.
| Specifications | Value |
|---|---|
| No. | 984527 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D24C DIESEL |
| Rated power (kw/rpm) | 38.9/2100 |
| Cylinder diameter × stroke (mm) | 90 x 94 |
| Number of cylinders (PCS) | 4 |
| Working form | In-line, turbocharged |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 9 |
| Bucket digging force (kN) | 4.2ton |
| Rod digging force (kN) | 2.8ton |
| Travel speed (km/h) | 4.2/2.3 |
| Turning torque (Nm) | 971 |
| Type of walking hydraulic motor | Axial piston hydraulic motor |
| Maximum flow of main pump (l/min) | 2 x 57.8 |
| Traveling Hydraulic Circuit (Mpa) | 240 |
| Rotary Hydraulic Circuit (Mpa) | 220 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 240 |
| Fuel Tank (L) | 115 |
| Hydraulic System (L) | 62 |
| Total transport length (mm) | 5870 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 1983 |
| Full cab height (mm) | 2565 |
| Counterweight ground clearance (mm) | 350 |
| Minimum ground clearance (mm) | 700 |
| Minimum turning radius of front working device (mm) | 2365 |
| Back end turning radius (mm) | 1660 |
| Onboard width (mm) | 1850 |
| Total track length (mm) | 2540 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Maximum digging radius (mm) | 6136 |
| Maximum digging depth (mm) | 3807 |
| Maximum excavation height (mm) | 5788 |
| Maximum unloading height (mm) | 4064 |
| Maximum vertical digging depth (mm) | 3037 |
| Dodging plate width × height (mm) | 2000 x 350 |
| Maximum excavation radius of stop surface (mm) | 6000 |
| Maximum effective digging depth (mm) | 3388 |
