| Specifications | Value |
|---|---|
| No. | 964163 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
Description
Doosan 380 Second-hand excavator on Sale at Special Price We currently have a second-hand Doosan 380 model excavator on sale at a special price. This is a device with stable performance and extremely high cost performance. Since its commissioning, this excavator has accumulated a working time of only 2,500 hours, which is far lower than the average service life of similar equipment. Therefore, its mechanical condition remains at a very good level. In terms of the power system, the Doosan 380 is equipped with a highly efficient and energy-saving diesel engine, which not only offers strong power but also has excellent fuel economy, capable of meeting the operational requirements under various complex working conditions. Meanwhile, this machine is also equipped with an advanced electronic control system, which can precisely adjust the engine speed and output power, ensuring high efficiency and safety during operation. The hydraulic system adopts high-quality components provided by internationally renowned brands, featuring fast response speed and flexible operation. Whether in terms of excavation depth or lifting capacity, it is in the leading position among similar products. In addition, this machine has particularly strengthened the
