| Specifications | Value |
|---|---|
| No. | 969872 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
Description
【 Premium Recommendation 】 The top-quality Doushan 380 excavator of 2020 is your ideal choice for seeking efficient, durable and cost-effective second-hand construction machinery. Since its purchase, this excavator has only been in operation for about 1,500 hours and is in very good condition, far shorter than the average usage time of similar products. This means that it still has a long service life waiting for its new owner to start excavating. In terms of power, this machine is equipped with a powerful Cummins QSB6.7 engine, which is renowned for its low fuel consumption and high efficiency, and can provide stable and reliable power support for your project. Meanwhile, advanced electronic control injection technology has significantly improved fuel economy and reduced operating costs. In terms of the hydraulic system, Doosan's unique intelligent control system is adopted, ensuring smoothness and accuracy during the operation process. Whether it is excavation or loading operations, they can be handled with ease. In addition, the efficient cooling system and filtration device effectively extend the service life of hydraulic components and reduce maintenance frequency. Most importantly, considering its outstanding performance compa
