Product Description
This 2019 Doushan 380-9C excavator is renowned for its outstanding performance and excellent durability, making it an ideal choice for your construction site. The current working time of this equipment is only 8,000 hours. It is in good overall condition, with the original paint and appearance as good as new, fully demonstrating its excellent maintenance record. In terms of the power system, the Doosan 380-9C is equipped with an efficient six-cylinder turbocharged engine (the specific model might be Scania DC13 083A), with a maximum output power of approximately 405 horsepower, ensuring strong power output and smooth operation under various working conditions. This engine not only has abundant power, but also features excellent fuel economy and low emissions, meeting strict environmental protection standards. In terms of the hydraulic system, Doosan 380-9C is equipped with advanced variable piston pumps and high-performance hydraulic motors, which can provide a stable and precise operating experience. This hydraulic system has been meticulously designed to ensure rapid response and efficient operation, capable of handling tasks such as excavation, loading, and crushing with ease. In addition, its intelligent control system can automa
| Specifications | Value |
|---|---|
| No. | 978694 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
