Product Description
Built for demanding construction and excavation work, this 2019 Doosan DX80 delivers reliable 8-ton performance with proven Yanmar 4TNV98 engine technology. Operating at 41.4kW rated power, this compact excavator handles precise digging operations with 56kN bucket force and 4165mm maximum dig depth.
Key operational specifications include:
- 0.30-0.32m³ bucket capacity for efficient material handling
- 6350mm maximum reach radius covers extensive work areas
- 30° climbing capability tackles challenging terrain
- 4.9km/h travel speed ensures productive site mobility
- 145L fuel capacity supports extended operating periods
Currently located in Jinan, Shandong, this machine features dual hydraulic pumps (75.6L/min each) and 28MPa working pressure for consistent performance across grading, trenching, and demolition applications. Compact 2290mm transport width allows easy trailer loading while maintaining full-size excavation capabilities. Ready for immediate deployment on your next project.
| Specifications | Value |
|---|---|
| No. | 982467 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
